NDJ-9s 8s 5s Laboratory Battery Electrode Slurry Viscometer Viscosity Tester

Brand Name : ACEY

MOQ : 1 Set

Payment Terms : T/T,PayPal,L/C,Western Union

Supply Ability : 200 Sets/Month

Delivery Time : 7~35 Days

Measuring range : 1～2,000,000

Display mode : liquid-crystal display

Certification : CE

Place of Origin : China

Dimensions : 300 × 300 × 450(mm)

Warranty : 1 Year Warranty With Lifetime Support

After-sales Service : 24/7 Technical Support

Packaging Details : Plywood Case

Model Number : NDJ-5S/8S/9S

Price : USD 560~580/Set

Data processing software : option

Sample size : 250 – 400ml

Input power : AC 220V / 50Hz

Contact Now

NDJ-9s 8s 5s Laboratory Battery Electrode Slurry Viscometer Viscosity Tester
Product Overview

The NDJ-5S/8S/9S portable viscometer features an LCD backlit display and supports programmable settings, automatic control, timed measurement, auto-scanning, and error alerts. The screen clearly displays viscosity, temperature, measurement duration, rotational speed, rotor number, torque percentage, measurement range, and other relevant parameters.

This instrument is widely used across industries and research sectors handling fluids and semi-fluids, including lubricants, paints, coatings, textiles, food, slurries, cosmetics, adhesives, and similar materials.

Key Features
  • Direct LCD screen display of measurement data without requiring calculations
  • Advanced microcomputer drive technology with imported stepper motor for accurate speed and reliable operation
  • Switching power supply technology ensures measurement accuracy unaffected by power fluctuations
  • Convenient level display device located on the front of the viscometer
  • Viscosity value display accuracy to two decimal places (0.01mPa.S) across all ranges
  • Timing measurement function for detecting non-Newtonian liquids
  • Small sample adapters require only 18ml per measurement
  • Automatic scanning function recommends optimal rotor and speed combinations
  • Automatic display of maximum viscosity range for selected combinations
  • Print interface for direct connection to micro printing machines
  • Optional data processing software for recording real-time viscosity variations
Technical Specifications
Instrument Model NDJ-5S NDJ-8S
Display Mode Liquid-crystal display
Speed (r/min) 6 / 12 / 30 / 60 0.3/0.6/1.5/3/6/12/30/60
Rotor 1#, 2#, 3#, 4# (0# rotor optional for ultra low viscosity below 15)
Measuring Range 1～100,000 1～2,000,000
Sample Size 250-400ml
Viscosity Display Accuracy 0.01mPa.S
Measurement Error ±3% (Newtonian liquid)
Repetitive Error ±1.5% (Newtonian liquid)
Sample Amount 18ml (per measurement)
Timing Measurement Standard configuration
Temperature Measurement Standard configuration
Data Output Interface Standard configuration
Working Power Supply 110V / 60Hz, 220V / 50Hz
Outline Dimension 300 × 300 × 450(mm)
Product Image
